SPCF steel coil,JIS G3141 SPCF steel coil cold commercial Tolerance

2016/8/29 15:56:23

JIS G3141 SPCF steel coil cold commercial is deep drawing quality non aging cold rolled steels, which are consumed for drawing applications. The SPCF steel coil is different with SPCE steel in a way that mechanical properties of SPCE steel change little with its age unlike the SPCE steel.

SPCF steel coil,JIS G3141 SPCF steel coil cold commercial Tolerance

JIS G3141 SPCF steel coil is widly used in home appliances, constructions, machineries, profile, oil drum and tubes. SPCF steel coil cold commercial is different with SPCE steels in a way that mechanical properties of SPCE steel change little with its age unlike the SPCE steel. JIS G3141 SPCF steel coil is deep drawing quality non aging cold rolled steels, which are consumed for drawing applications.

SPCF steel coil Chemical composition(%)

C≤0.08 Mn≤0.45 P≤0.03 S≤0.03

JIS G3141 SPCF steel coil cold commercial Mechanical property

Yield strength Max Mpa:210 Tensile strength Min Mpa:270 Elongation Min %:40

JIS G3141 SPCF steel coil cold commercial Specification

Thickness: 0.30mm to 3.50mm

Tolerance of thickness: +/-0.03mm

Normal width: 914mm, 1000mm, 1200mm, 1219mm, 1250mm

Tolerance of width: +/-5.00mm (aiming to +/-2.00mm)

Coil weight: 4 - 8MT, suitable to be loaded in 20' container

Coil ID: 508mm

Surface treatment: Oiled, brightly

Packing: Sea worthy

JIS G3141 SPCF steel coil cold commercial is the main product Bebon international operations. We have a high quality logistics team who make sure the fast delivery time and shipment. If you need of SPCF steel coil,pls contact us or email to us.
