Common size for SGLCD+AZ hot aluminum zinc steel
Thickness of SGLCD+AZ hot aluminum zinc steel plate: 0.23 to 1.30mm
Width of SGLCD+AZ hot aluminum zinc steel plate:710 to 1250mm
Length of SGLCD+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of SGLCD+AZ steel strip:508mm
Type of aluminum zinc coating of SGLCD+AZ
SGLCD+AZ Normal spangle finish coating: coating formed as a result of unrestricted growth of aluminum zinc crystals during normal solidification
SGLCD+AZ Smooth finish: smooth finishing produced by skin-passing the coated material in in order to achieve an improved surface condition as compared with the normal as coated product.
Surface treatment of SGLCD+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for SGLCD+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
SGLCD+AZ |
0.08 |
0.40 |
0.030 |
0.02 |
≤0.22 |
Mechanical property of SGLCD+AZ aluminum and zinc steel
|
Grade |
Yield |
Tensile |
Elongation after fracture |
|
|
＜ |
≥ |
|||
|
SGLCD+AZ |
300 |
420 |
24 |
26 |
Equal material for SGLCD+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
DC52D+AZ |
G3+AZ |
DX52D+AZ |
DS |
SGLCD |
2 |
The coating weight of SGLCD+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of SGLCD+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Package for hot aluminum zinc silicon:
metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
Application to SGLCD+AZ hot rolled aluminum and zinc plate
1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument
Electric control cabinet, industry refrigeration cabinets, vending machines
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity
Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to contact us if you require any hot rolled zinc aluminum steel products.
