SGLCC+AZ Hot aluminum zinc steel

2014/4/30 2:04:55

Type of SGLCC+AZ aluminum zinc coating
Normal spangle finish coating: coating formed as a result of unrestricted growth of aluminum zinc crystals during normal solidification
Smooth finish: smooth finishing produced by skin-passing the coated material in in order to achieve an improved surface condition as compared with the normal as coated product.
Surface treatment of SGLCC+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U

Common size for SGLCC+AZ hot aluminum zinc steel
Thickness of SGLCC+AZ hot aluminum zinc steel plate: 0.22 to 1.Width of SGLCC+AZ hot aluminum zinc steel plate:690 to 1250mm
Length of SGLCC+AZ hot aluminum zinc steel plate:900 to 6000mm
Inner diameter of SGLCC+AZ steel strip:508mm

SGLCC+AZ aluminum and zinc

Chemical composition for SGLCC+AZ aluminum and zinc steel

Grade	C	Mn	P	S	other alloy element
SGLCC+AZ	0.1	0.45	0.030	0.02	≤0.22

Mechanical property of SGLCC+AZ aluminum and zinc steel

Grade	Yield strength Mpa(max)	Tensile strength Mpa(max)	Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm)
			＜	≥
SGLCC+AZ	-	500	22	24

Equal material for SGLCC+AZ aluminum and zinc steel

Q/BQB 425-2004	AS 1397-2001	EN10215-1995	ASTMA792M-02	JISG3321-1998	ISO9364-2001
DC51D+AZ	G2+AZ	DX51D+AZ	CS type B type C	SGLCC	1

The coating weight of SGLCC+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of SGLCC+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Package for hot aluminum zinc silicon:
metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity

We, bebon international CO.,ltd can offer all above technical details. For the special requirements for the hot dipped aluminum zinc steel products, we may require negotiations between the supplier and customer. In this way, we can meet customer’s specific requirements. Please contact us freely if you have any questions or inquiry in hand about hot dipping aluminum zinc steel products. We will offer you the most professional service and quality.
