Common size for SGLC490+AZ hot aluminum zinc steel
Thickness of SGLC490+AZ hot aluminum zinc steel plate: 0.23 to 1.30mm
Width of SGLC490+AZ hot aluminum zinc steel plate:710 to 1250mm
Length of SGLC490+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of SGLC490+AZ steel strip:508mm
Surface of structural of SGLC490+AZ hot aluminum zinc steel:
spangle coating: N
finishing zinc surface:S
Surface treatment of SGLC490+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for SGLC490+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
SGLC490 |
0.3 |
1.60 |
0.100 |
0.035 |
≤0.22 |
Mechanical property of SGLC490+AZ aluminum and zinc steel
|
Grade |
Yield |
Tensile |
Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm) |
|
SGLC490 |
350 |
420 |
14 |
Equal material for SGLC490+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
S350GD+AZ |
G350+AZ |
S350GD+AZ |
345 Class1 |
SGLC490 |
350 |
The coating weight of SGLC490+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of SGLC490+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Package for hot aluminum zinc silicon:
metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
We, bebon international CO.,ltd can offer all above technical details. For the special requirements for the hot dipped aluminum zinc steel products, we may require negotiations between the supplier and customer. In this way, we can meet customer’s specific requirements. Please contact us freely if you have any questions or inquiry in hand about hot dipping aluminum zinc steel products. We will offer you the most professional service and quality.
