DC52D+AZ Hot aluminum zinc steel

2014/4/29 1:19:22

Common size for DC52D+AZ hot aluminum zinc steel

Thickness of DC52D+AZ hot aluminum zinc steel plate: 0.23 to 1.30mm

Width of DC52D+AZ hot aluminum zinc steel plate:710 to 1250mm

Length of DC52D+AZ hot aluminum zinc steel plate:1000 to 6000mm

Inner diameter of DC52D+AZ steel strip:508mm

Surface of structural of DC52D+AZ hot aluminum zinc steel:

spangle coating: N

finishing zinc surface:S

Surface treatment of DC52D+AZ hot aluminum zinc steel:

Los acid passivation:C

Smear oil: O

Los acid passivation and oil: CO

Fingerprint resistant membrane: UF

Un-treatment: U

DC52D+AZ aluminum and zinc

Chemical composition for DC52D+AZ aluminum and zinc steel

Grade	C	Mn	P	S	other alloy element
DC52D+AZ	0.08	0.40	0.030	0.02	≤0.22

Mechanical property of DC52D+AZ aluminum and zinc steel

Grade	Yield strength Mpa(max)	Tensile strength Mpa(max)	Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm)
			＜	≥
DC52D+AZ	300	420	24	26

Equal material for DC52D+AZ aluminum and zinc steel

Q/BQB 425-2004	AS 1397-2001	EN10215-1995	ASTMA792M-02	JISG3321-1998	ISO9364-2001
DC52D+AZ	G3+AZ	DX52D+AZ	DS	SGLCD	2

The coating weight of DC52D+AZ aluminum and zinc

Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2

The standard weight of DC52D+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2

When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.

Package for hot aluminum zinc silicon:

metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.

Application to DC52D+AZ hot rolled aluminum and zinc plate

1, construction industry

House top, external house, garage door, fence, window-shades

2, household appliance industry:

oven, explosion-proof strip, solar water heaters, electric parts

3,automobile industry

Car muffler, exhaust pipe, signboard

4, industrial instrument

Electric control cabinet, industry refrigeration cabinets, vending machines

Features for hot rolled aluminum zinc steel:

Formability, heat resistance, high reflectivity

Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to contact us if you require any hot rolled zinc aluminum steel products.
