Common size for S350GD+AZ hot aluminum zinc steel
Thickness of S350GD+AZ hot aluminum zinc steel plate: 0.22 to 1.30mm
Width of S350GD+AZ hot aluminum zinc steel plate:700 to 1250mm
Length of S350GD+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of S350GD+AZ steel strip:508mm
Surface of structural of S350GD+AZ hot aluminum zinc steel:
spangle coating: N
finishing zinc surface:S
Surface treatment of S350GD+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for S350GD+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
S350GD+AZ |
0.3 |
1.60 |
0.100 |
0.035 |
≤0.22 |
Mechanical property of S350GD+AZ aluminum and zinc steel
|
Grade |
steel number |
symbol for the |
Yield |
Tensile |
Min Elongation A80 % min |
|
S350GD+AZ |
1.0529 |
AZ |
350 |
420 |
16 |
Equal material for S350GD+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
S350GD+AZ |
G350+AZ |
S350GD+AZ |
345 Class1 |
SGLC490 |
350 |
The coating weight of S350GD+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of S350GD+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Application to S350GD+AZ hot rolled aluminum and zinc plate
1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument
Electric control cabinet, industry refrigeration cabinets, vending machines
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity
Package for hot aluminum zinc silicon: metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material are made under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to contact us if you require any hot rolled zinc aluminum steel products.
