Q690D Galvanized steel coil is a high strength welded structural steel. Wherein Q represents the yield strength, the yield strength value representative of 690, D level representative of the steel sheet.
GB/T16270 Q690D Carbon Structural Galvanized Steel coil may be referred to the yield strength 690Mpa resistance to low temperature high-strength steel. Q690D Galvanized Steel coil high yield and tensile strength, are widely used in mining machinery, engineering machinery, such as hydraulic support, port cranes, flatbed trucks.
GB/T16270 Q690D Carbon Structural Galvanized Steel coil Specification
Length:Coil
Width: 900-1300mm
Thickness: 0.2mm-1.2mm
GB/T16270 Q690D Galvanized Steel coil Chemical composition(%)
C≤0.18 Si≤0.60 Mn≤2.0 P≤0.030 S≤0.025 Ni≤0.80 Cr≤1.00 Mo≤0.30 Nb≤0.11 Ti≤0.02 B≤0.004 Carbon equivalent formula: CEV = C + Mn / 6 + (Cr + Mo + V) / 5 + (Ni + Cu) / 15
Q690D Carbon Structural Galvanized Steel coil Mechanical property
Tensile Strength(MPa):630-690 Yield Strength(MPa):710-940 Elongation in 2 in.(50mm) min %:14 Impacting Test Temperature(°C): 0,-20,-40,-60
Technique: Cold Rolled
Surface Treatment: Galvanized
Delivery status
Steel is usually quenched state of delivery, but also for special state of delivery according to customer requirements.
GB/T16270 Q690D Carbon Structural Galvanized Steel coils were primly dealed in the Bebon International.We are offer to the highest quality and service of Q690D Carbon Structural Galvanized Steel coils.If you need it,pls contact us freely.
