S250GD+Z, S250GD+ZF is a kind of hot dipped galvanized steel under the standard Q/BQB 420-2003 and it is a kind of low alloy steel some with the grade S220GD+Z, S220GD+ZF.
The figure 250 in the grade S250GD+Z, S250GD+ZF means the minimum yield strength is 250Mpa.
S250GD+Z, S250GD+ZF Chemical composition:
Grade |
Chemical composition % |
|||||
|
C |
Si |
Mn |
P |
S |
Alt |
|
|
S250GD+Z, S250GD+ZF |
0.16 |
--- |
0.6 |
0.035 |
0.035 |
0.015 |
S250GD+Z, S250GD+ZF Mechanical Property:
STEEL GRADE |
Tensile Strength |
Yield Strength |
Elongation% min |
The coating adhesion |
|
|
min |
min |
<0.7mm |
>0.7mm |
a=thickness |
|
|
S250GD+Z, S250GD+ZF |
330 |
250 |
17 |
19 |
1a |
a means when nominal thickness > 1.5 mm, the diameter of curved heart is 40.
