DC56D+Z Hot-dip galvanized steel

2014/4/29 23:43:23

DC56D+Za is a kind of hot dipped galvanized steel under the standard Q/BQB 420-2003. It is widely used for the production of automobile, construction, household appliances and other industries both inside and outside covering parts and components.
DC56D+Za Chemical composition:

Grade	Chemical composition %
Grade	C max	Si max	Mn max	P max	S max	Alt min	Ti max	Nb max
DC56D+Za	0.01	0.10	0.30	0.025	0.020	0.015	0.1	0.1

DC56D+Za Mechanical Property:

STEEL GRADE	Tensile Strength (Mpa)	Yield Strength (Mpa)	n90	r90	Elongation% min (Lo=80mm b=20mm)		The coating adhesion (The heart bending diameter )
STEEL GRADE	Tensile Strength (Mpa)	Yield Strength (Mpa)	min	min	<0.7mm	>0.7mm	<140/140	>140/140-175/175	>175/175
DC56D+Za	270-350	120-180	0.21	1.9	38	40	0a	1a	2a

a means when the thickness is more than 1.5mm, the minimum value r90 can lower 0.2.
b means when the thickness not more than 0.7mm, the minimum value r90 can lower 0.2, n90 can lower 0.01.
c means For difference thickness of coating products, thick coating surface as the outer surface of the bending test.

Bebon is a professional company, we can offer all kinds of steel processing service. We are always dependable and excellent quality products, an obvious commitment from your highest levels of management and all your employees to be able to keep up this outstanding performance order after order. If you have requirement for DC56D+Za hot hot dipped galvanized steel, please email to us.
