DC54D+Z Hot-dip galvanized steel

2014/4/29 23:36:49

DC54D+Z Hot-dip galvanized steel

DC54D+Z is used for special deep stamping. It is a special low carbon steel under the standard Q/BQB 420-2003. DC54D+Z is a kind of cold rolled basal steel plate. So the size for DC54D+Z 0.3-3.0mm thickness.
DC54D+Z Chemical composition:


Grade

Chemical composition %

C
max

Si
max

Mn
max

P
max

S
max

Alt
min

Ti
max

Nb
max

DC54D+ Z

0.01

0.10

0.30

0.025

0.020

0.015

0.1

0.1

DC54D+Z Mechanical Property:


STEEL GRADE

Tensile Strength
(Mpa)

Yield Strength
(Mpa)

n90

r90

Elongation% min
(Lo=80mm b=20mm)

The coating adhesion
(The heart bending diameter )

 min

min

<0.7mm

>0.7mm

<140/140

>140/140-175/175

>175/175

DC54D+ Z

270-350

140-220

0.18

1.6

34

36

0a

1a

2a

a means when the thickness is more than 1.5mm, the minimum value r90 can lower 0.2.
b means when the thickness not more than 0.7mm, the minimum value r90 can lower 0.2, n90 can lower 0.01.
c means For difference thickness of coating products, thick coating surface as the outer surface of the bending test.

The material St06Z is the old grade for DC54D+Z and they are same for the chemical composition and mechanical property.
Bebon International as a professional DC54D+Z supplier will try our best to give our clients the best service, quality and price. If you have any inquiry about DC54D+Z, please do not hesitate to contact our sales.
