Common size for 345 Class1+AZ hot aluminum zinc steel
Thickness of 345 Class1+AZ hot aluminum zinc steel plate: 0.23 to 1.30mm
Width of 345 Class1+AZ hot aluminum zinc steel plate:710 to 1250mm
Length of 345 Class1+AZ hot aluminum zinc steel plate:1000 to 6000mm
Inner diameter of 345 Class1+AZ steel strip:508mm
The price of 345 Class1+AZ is also various from different surface. There are two common
surface condition: spangle coating: N and finishing zinc surface:S.
Surface treatment of 345 Class1+AZ hot aluminum zinc steel:
Los acid passivation:C
Smear oil: O
Los acid passivation and oil: CO
Fingerprint resistant membrane: UF
Un-treatment: U
Chemical composition for 345 Class1+AZ aluminum and zinc steel
|
Grade |
C |
Mn |
P |
S |
other alloy element |
|
345 Class1+AZ |
0.3 |
1.60 |
0.100 |
0.035 |
≤0.22 |
Mechanical property of 345 Class1+AZ aluminum and zinc steel
|
Grade |
Yield |
Tensile |
Elongation after fracture (L0=80mm, b=20mm)% min thickness(mm) |
|
345 Class1+AZ |
350 |
420 |
14 |
Equal material for 345 Class1+AZ aluminum and zinc steel
|
Q/BQB 425-2004 |
AS 1397-2001 |
EN10215-1995 |
ASTMA792M-02 |
JISG3321-1998 |
ISO9364-2001 |
|
S350GD+AZ |
G350+AZ |
S350GD+AZ |
345 Class1 |
SGLC490 |
350 |
The coating weight of 345 Class1+AZ aluminum and zinc
Bebon international can offer the weight of aluminum and zinc from 30/30g/m2 to 90/90g/m2
The standard weight of 345 Class1+AZ aluminum and zinc is 30/30g/m2 , 40/40g/m2, 50/50g/m2, 60/60g/m2, 75/75g/m2 , 90/90g/m2
When the coating weight of 50/50g/m2, the thickness of coating layer is 13.3μm.
Package for hot aluminum zinc silicon:
metal band stapping, out sided diameter ring, making sheet, metal protective steel sheet, metal steel sheet.
Application to 345 Class1+AZ hot rolled aluminum and zinc plate
1, construction industry
House top, external house, garage door, fence, window-shades
2, household appliance industry:
oven, explosion-proof strip, solar water heaters, electric parts
3,automobile industry
Car muffler, exhaust pipe, signboard
4, industrial instrument
Features for hot rolled aluminum zinc steel:
Formability, heat resistance, high reflectivity
Bebon international company can offer all kinds of hot rolled zinc and aluminum steel products. All the material are
made under the standard. We can bare any third party to inspect the products, If the product is fake, we can bare all
the losses. Bebon international Co.,ltd prefer the long terms relationship with customer. Please don’t hesitate to
contact us if you require any hot rolled zinc aluminum steel products.
